Deadlatch Lock, 1-1/8 Inch Backset, Reversable Handing - No Face plate

This item has Reversable Handing (left and right)

Deadlatch Mortise Lock for store front aluminum narrow style doors
Steel construction Spring latch lock for commercial doors
Steel construction Dead Latch lock for commercial storefront doors
Spring Latch Extends 3/4"
Deadlatch may allow exit only when used with inside Lever or Paddle
Commonly used for traffic control after hours or when someone wants door to lock when closing.
Sold each

Description: Mortise Lock 1-1/8 inch Backset, Steel, Aluminum Finish
Material: Steel
Faceplate Color: NONE
Backset: 1-1/8 inch with 1/8 inch thick faceplate attached
Backset is measured from edge of lock face to center of cylinder
Handed: Reversible for left or right hand doors

PLEASE NOTE THE FOLLOWING:
1). Deadlatch locks comes in 3 backsets:
31/32, 1-1/8, 1-1/2 inch, please check measurements carefully.

2). Reversing the handing:  Some locks have a latch that can be pulled out and rotated 180 degrees.  If the latch will not pull out and rotate, see handing article



Article: Changing the Handing on a Commercial Mortise Deadlatch

Specifications

Lock Backset 31/32 inch - 1 1/8 inches
Case Depth 1.63 inches - 1.78 inches
Backset: 31/32 inch, 1 1/8 inches
Hand: Non handed, easily reversible
Case Dimensions: 7/8 inch W x 6 inches L x Depth specific to backset
Latchbolt:
Deadlatch - 1/2 inch W x 1.0 inch L x 1/2 inch throw
Deadlatches: Zinc alloy latchbolt with Delrin plastic insert, auxiliary bolt zinc diecast, deadlocks latchbolt and prevents manipulation
