Sentry Multipoint Lock, 60/140 Tongue Version for 80" tall Doors

Part Number: 49917168
Price: $195.00

Sentry MP Lock, Tongue Version 2-3/8 inch backset, 5-1/2 inch hole spacing
Entry Door Multipoint locking system with deadlocking tongues
90 degree consumer friendly locking operation
Visual Lock and unlock indicator
Used by Bilt Best from 2006-2010

Faceplate Width: 25/32 inch (20mm)
Backset: 2-3/8 inch (60mm)
Handle to Cylinder PZ: 5-1/2 inches (139.7mm)
Deadbolt Throw: 1 inch (25.4mm)
Handed: Spring latch is field reversible with a screw drive
Material: Steel, Painted Silver, available in Stainless Steel
Construction: one (1) piece, for ease of installation. croppable, may not run full length of door

Number Material Size Bottom Tongue Top Tongue Backset
73228768Steel 6’8″ 19.443″ 32.555″ 2-3/8"
73228780Steel 8’0″ 22.318″ 45.68″ 2-3/8"

NOTE:
The Tongue version will work with lever/lever handles and with the grip/teacup handlesets.
The triple latch version will only work with lever/lever handles and will not work with the grip/teacup handlesets.
