Trilennium Peachtree IPD Dummy Fixed Levers 1-3/4 Hinged door

Part Number: 40066
Price:$175.00 to $225.00
Trilennium Peachtree IPD Dummy Fixed Levers 1-3/4 inch thick hinged door used by Peachtree on their Citadel IPD doors

Application: Dummy Handle
Style: Traditional
Handle to Cylinder PZ Distance: 6 inch es
Keyway: NONE, this is a dummy function
Door thickness: 1-3/4 inches (45mm)
Installation Screw Holes: 5-3/8 inches
Escutcheon Plate Width: 2-7/16 inches
Escutcheon Plate Height: 11 inches
Lock Cross bore: Fits 1-11/16
Door Thickness: 1-3/4" (45mm)
Handle Projection: 2-9/32 inches

Available colors: Bright Brass, Victorian Bronze, Satin Nickel

Note: This is made for 1-3/4 inch thick doors. For 2-1/4 inch thick doors, conversion kit #40039-WR will be needed

http://www.wfmfg.com/pages/trilennium_hardware.html

W&F Trilennium  Part numbers for 1-3/4" Door

HORL-DUM-PB-175 = Bright Brass

HORL-DUM-SN-175 = Satin Nickel

HORL-DUM-VB-175 = Victorian Bronze

HORL-DUM-SNTL-175 = Satin Nickel, TriLast Finish

HORL-DUM-VBTL-175 = Victorian Bronze, TriLast Finish
