Low profile steel commercial door lite frames.
Used on 1-3/4 inch thick hollow metal or wood doors.
Tip To Tip frame: 8-1/16 x 23 inches
Door Cut Out: 7 x 22 inches
Actual Glass Size: 21 x 6 inches ( not included)
Exposed Daylight Glass: 5 x 20 inches
Number of Screws: 8
Accommodates Glass thickness 3/16", 1/4" or 5/16" (not included)
Standard screw together low profile frame
18 ga. cold rolled steel
Mitered and welded corners
Welded reinforcing clips at corners
Counter-sunk mounting screw-holes
(1) Steel Frame with Double-Faced Foam Tape for Glass Installation
(8) #8 x 1-5/8 Phillips head SMS
