Savio 3-wing Clamp Hinge 1122.201

3 wing Pre-assembled aluminum hinge, nylon bushing, extractable pin, indented plates with countersunk screw heads.

Application: Metal Doors and Windows
Overall Length: 3-5/8 inch (92.5mm)
Load Capacity: 2 hinges 90kg, 3 hinges100kg
Screws: M5x9 Stainless Steel
Hinge Material: Extruded Aluminum
Color / Finish: Silver ( argento)
Sold Each

NOTE:
Many hinges look the same, the profiles are differnt
Savio Hinges are marked with " AV "
No Refunds, No Returns on Clamp Hinges
