Rhino Active 35/92 Europa, 5 Point Hook / Shootbolt - SS
G-U/Ferco active 5-point lock with 2 Rhino Hookbolts, 2 Shootbolts and a Deadbolt.
This lock kit fits door panels up to 90 inches tall.
For door panels greater than 90 inches, extensions can be purchased separately.
Please contact our office for ordering information.
G-U/Ferco Rhino Lock Specs:
Handle Height: 35 inches
Backset: 35 mm
Handle PZ: 3-5/8 inch (92 mm)
Overall Length: 79-1/4 inches (2060 mm)
Adjustable Length: 79-1/4 inches maximum. Gear is Crop-able for shorter heights
Faceplate Width: 5/8 inch (16 mm)
Faceplate Finish: Stainless Steel
Lock Body Style: Europa - key below handle
Handle to Top Hook: 22-38 inches (center of handle to center of hook)
Handle to Bottom Hook: 25-15/16 inches (center of handle to center of hook)
Cylinder Type: American Cylinder with flat tail piece
Contents:
Main lock body with Hookbolts on top and bottom and Shootbolts on top and bottom.
Stainless Steel screws to match Faceplate.
Priced and sold as a KIT.
